Typical Values

STANDARD PRODUCT DESCRIPTION COMPOSITION
% BY WEIGHT 		COMPOSITION
% BY VOLUME 		DENSITY VOC
less Water
Code Pigment CI Name Pigment Vehicle Volatiles Pigment Vehicle Volatiles lb/gal Sp. Gr. lb/gal gr/l
87B1204 Phthalo Blue RS B 15:2 22.0 31.8 46.2 11.9 29.7 58.4 8.20 0.98 3.79 444
87B1289 Phthalo Blue RS LC B 15:2 48.9 18.4 32.7 28.4 21.1 50.5 10.03 1.20 3.27 383
87B1250 Milori Blue B 27 33.5 26.9 39.6 18.7 27.4 53.9 8.85 1.06 3.51 410
87G1705 Phthalo Green GR 7 26.0 26.9 47.1 13.1 25.9 61.0 8.38 1.00 3.95 462
87K1383 Tinting Black BK 7 30.0 23.8 46.2 16.7 22.7 60.6 8.38 1.00 3.87 452
87K1350 Masstone Black BK 7 21.2 33.4 45.4 11.5 30.8 57.5 8.15 0.98 3.70 433
87K1362 Bone Black BR 9 30.0 29.3 40.7 13.9 30.2 55.9 8.96 1.07 3.65 427
87N1535 Burnt Umber BR 7 45.0 15.8 39.2 16.6 19.3 64.1 10.60 1.27 4.15 486
87N1577 Burnt Sienna BR 7 52.0 16.8 31.2 20.1 23.1 56.8 11.82 1.42 3.69 432
87N1582 Raw Umber BR 7 43.0 25.0 32.0 16.7 30.9 52.4 10.67 1.28 3.41 400
87Q1901 DNA Orange OR 5 35.0 29.3 35.7 21.4 30.1 48.5 8.87 1.06 3.16 370
87Q1979 Diarylide Orange OR 34 25.0 35.3 39.7 17.1 33.4 49.5 8.17 0.99 3.24 379
87R1601 Red Oxide Light R 101 60.0 22.4 17.6 21.5 38.6 39.9 14.97 1.79 2.64 308
87R1602 Red Oxide Medium R 101 63.0 19.9 17.1 24.0 35.6 40.4 15.57 1.87 2.66 311
87R1682 Red Oxide Medium Dark R 101 66.0 19.2 14.8 28.3 35.5 36.2 16.10 1.93 2.38 279
87R1600C Transparent Red Oxide R 101 36.0 24.5 39.4 10.8 28.6 60.6 9.98 1.20 3.93 461
87R1620 Naphthol Red YS R 188 25.0 26.0 49.0 16.5 23.7 59.8 7.92 0.95 3.88 454
87R1625 Naphthol Red BS R 170 27.0 35.0 38.0 19.6 32.9 47.5 8.17 0.98 3.11 363
87R1630 Quinacridone Red V 19 20.0 35.2 44.8 12.1 32.6 55.3 8.06 0.97 3.61 423
87R1664 Toluidine Red Medium Light R 3 35.0 29.9 35.1 25.4 29.2 45.4 8.47 1.02 2.97 348
87R1655 Lithol Rubine R 57:1 20.7 34.8 44.5 12.2 32.4 55.4 8.11 0.97 3.61 422
87V1801 Carbazole Violet V 23 15.9 34.7 49.4 10.1 31.0 58.9 7.76 0.93 3.83 449
87V1810 Quinacridone Violet V 19 20.0 37.3 42.7 13.1 34.5 52.4 8.03 0.96 3.43 401
87W1150 Titanium Dioxide WH 6 65.0 17.6 17.4 29.5 30.5 40.0 15.14 1.81 2.63 308
87Y1406 Yellow Oxide Y 42 62.2 14.8 23.0 25.7 24.4 49.9 14.12 1.69 3.24 380
87Y1400C Transparent Yellow Oxide RS Y 42 31.4 32.0 36.6 10.9 35.4 53.7 9.59 1.15 3.51 410
87Y1403 Transparent Yellow Oxide GS Y 42 31.0 29.3 39.7 9.3 32.7 58.0 9.54 1.14 3.79 443
87Y1420 Monoazo Yellow Y 97 26.3 34.3 39.4 18.7 32.3 49.0 8.16 0.98 3.21 376
87Y1430 Isoindoline Yellow Y 139 25.0 34.1 40.9 15.3 32.4 52.3 8.27 0.99 3.38 395
87Y1477 Hansa Yellow Y 74 30.0 29.3 40.7 20.8 27.8 51.4 8.24 0.99 3.35 392

Download Printable Version

PanTINT® 87 Series 497 KB
Technical information regarding the composition, properties or use of products described herein is believed to be reliable. However, no representation or warranty is made with respect thereto except as made by Pan Technology in writing at the time of sale. Tests should be carried by qualified personnel and performance should be verified to insure suitability prior to use.Technical information regarding the composition, properties or use of products described herein is believed to be reliable. However, no representation or warranty is made with respect thereto except as made by Pan Technology in writing at the time of sale. Tests should be carried by qualified personnel and performance should be verified to insure suitability prior to use.
