PanTINT® 12 Series
Chip Dispersions in Universal Acrylic for Non-Aqueous Applications
Solvent-free chip dispersions for use in solvent borne and radiation cured coatings and inks. PanTINT 12 Colorants are based on a unique modified thermoplastic acrylic resin with exceptionally broad compatibility. Pigments used in the PanTINT 12 Series have been selected to meet the durability and transparency requirements of most high performance applications.
Recommended Use
- Aerosol Paints
- Aerospace Coatings
- Appliance Finishes
- Digital Printing Inks
- Furniture Finishes
- Gravure Inks
- Industrial Maintenance Coatings
- Machinery and Implement Enamels
- Automotive Refinish Coatings
- Marine Coatings
- Lacquers
- Adhesive Tapes
Compatibility
- Acrylic
- Vinyl Lacquer
- Vinyl Acrylic
- CAB
- Acrylate Monomer and Oligomer
- Cellulosic Lacquers
- Short Oil Alkyd
- Chlorinated Rubber
- Vinyl Toluene Alkyd
- Two Component Epoxy
- Silicone Alkyd
- Epoxy Ester
- Alkyd Urea
- Polyester
- Alkyd Melamine
- Single and Two Component Polyurethane
- Cellulosic Lacquer
Typical Values
| STANDARD PRODUCT DESCRIPTION | COMPOSITION
% BY WEIGHT |
COMPOSITION
% BY VOLUME |
DENSITY | |||||
|---|---|---|---|---|---|---|---|---|
| Code | Pigment | CI Name | Pigment | Vehicle | Pigment | Vehicle | lb/gal | Sp. Gr. |
| 12B1245 | Phthalo Blue RS, NCNF | B 15:2 | 42.0 | 58.0 | 32.9 | 67.1 | 10.62 | 1.27 |
| 12B1264 | Phthalo Blue GS | B 15:3 | 42.0 | 58.0 | 33.8 | 66.2 | 10.48 | 1.26 |
| 12G1740 | Phthalo Green YS | G 36 | 37.0 | 63.0 | 19.4 | 80.6 | 11.81 | 1.41 |
| 12K1313 | Tinting Black | BK 7 | 50.0 | 50.0 | 38.0 | 62.0 | 11.42 | 1.37 |
| 12K1367 | Masstone Black | BK 7 | 50.0 | 50.0 | 38.0 | 62.0 | 11.42 | 1.37 |
| 12K1366 | High Jet Black | BK 7 | 30.0 | 70.0 | 20.7 | 79.3 | 10.35 | 1.24 |
| 12Q1930 | Diarylide Orange | O 34 | 40.0 | 60.0 | 35.7 | 64.3 | 9.89 | 1.19 |
| 12R1633 | Napthol Red BS | R 170 | 40.0 | 60.0 | 37.9 | 62.1 | 9.56 | 1.15 |
| 12R1642 | Red Oxide Light | R 101 | 65.0 | 35.0 | 29.0 | 71.0 | 18.61 | 2.23 |
| 12R1659 | Transparent Red Oxide | R 101 | 55.0 | 45.0 | 23.1 | 76.9 | 15.73 | 1.89 |
| 12R1665 | Lithol Rubine | R 57:1 | 42.0 | 58.0 | 32.4 | 67.6 | 10.70 | 1.28 |
| 12V1839 | Carbazole Violet | V 23 | 23.0 | 77.0 | 18.5 | 81.5 | 9.81 | 1.18 |
| 12W1134 | Titanium Dioxide - Chalk Resistant | WH 6 | 65.0 | 35.0 | 34.1 | 66.2 | 17.28 | 2.07 |
| 12Y1462 | Transparent Yellow Oxide | Y 42 | 55.0 | 45.0 | 26.2 | 73.8 | 15.10 | 1.81 |
| 12Y1431 | Mono Azo Yellow GS | Y 97 | 40.0 | 60.0 | 34.5 | 65.5 | 10.06 | 1.21 |
| 12Y1438 | Isoindoline Yellow | Y 139 | 30.0 | 70.0 | 22.7 | 77.3 | 10.22 | 1.22 |
Incorporation
PanTINT 12 Colorants can often be incorporated in solvent thinned coatings by simple stirring. The most effective solvents for rapid solution of the carrier resin are ketones, aromatics, esters and glycol ethers. Addition of 5% aromatic to aliphatic solvents can be enough to achieve complete solution. For optimum results, first begin mixing of the coating base and then add PanTINT 12 Colorant under continuous agitation. Vigorous agitation and elevated temperatures may reduce the time required for complete solution.
