Typical Values
STANDARD PRODUCT DESCRIPTION COMPOSITION
% BY WEIGHT
COMPOSITION
% BY VOLUME
DENSITY
Code Pigment CI Name Pigment Vehicle Volatiles Pigment Vehicle Volatiles lb/gal Sp. Gr.
81B186 Phthalo Blue B 15:2 20.5 25.6 53.9 12.4 23.8 63.8 8.60 1.03
81G154 Phthalo Green G 7 21.4 28.3 50.3 10.2 27.7 62.1 9.00 1.08
81K245 Lamp Black BK 7 18.4 26.0 55.6 11.4 17.3 71.3 9.30 1.12
81N197 Burnt Umber BR 7 45.0 20.0 35.0 18.5 26.4 55.1 11.82 1.42
81Q167 Lead Free Orange OR 34/OR36 25.1 25.0 49.9 17.2 23.2 59.6 8.67 1.04
81R159 Quinacridone Red V 19 19.5 29.1 51.4 12.9 24.8 62.3 8.80 1.06
81R182 Red Iron Oxide YS R 101 64.0 11.2 24.8 24.9 20.1 55.0 16.24 1.95
81V166 Quinacridone Violet V 19 16.2 36.1 47.7 11.3 31.3 57.4 8.74 1.05
81Y124 Yellow Iron Oxide Y 42 54.4 11.9 33.7 21.0 18.0 61.0 13.33 1.60
81Y015 Light Organic Yellow Y 175 31.0 30.2 38.8 22.0 29.7 48.3 9.03 1.08
81Y025 L.F. Medium Yellow Y 151 25.6 27.3 47.1 18.7 24.6 56.7 8.89 1.07
81W093 Titanium Dioxide WH 6 68.0 13.0 19.0 33.8 24.0 42.2 16.58 1.99

Download Printable Version

PanTINT® 81 PanTINT® 81 (160 KB)

Technical information regarding the composition, properties or use of products described herein is believed to be reliable. However, no representation or warranty is made with respect thereto except as made by Pan Technology in writing at the time of sale. Tests should be carried by qualified personnel and performance should be verified to insure suitability prior to use.Technical information regarding the composition, properties or use of products described herein is believed to be reliable. However, no representation or warranty is made with respect thereto except as made by Pan Technology in writing at the time of sale. Tests should be carried by qualified personnel and performance should be verified to insure suitability prior to use.
